Features:
Four cutting modes: single, two, three, and four-sided moulding or planing
Planing capacity: 13" wide by 3/8" to 9"
2-sided planing or moulding capacity; 13 5/8" wide by 9" tall
4-sided planing or moulding capacity; 12" wide by 4" tall
Power Top horizontal spindle: One 7.5 HP (5.5 Kw) motor
Bottom horizontal spindle: One 5 HP (3.7 Kw) motor
Right & left spindles: Two 4.1 HP (3 Kw) motors
Feed system: One 1/2 HP (0.375 Kw) motor
Feed speed: Fully variable 11 to 52 fpm (3.35 to 15.85 m per minute)
Infeed and outfeed tables are included. Infeed table has an adjustable fence
MachineryAssociates.com listing
