Grizzly GO611X 16.5" Width Cap. Manual Dovetailing Machine, 1PH, 220V, 1PH, 2007 Lower Use
G0611X 16-1/2" Extreme Series Dovetail Machine
Produce strong and attractive half-blind dovetail joints at scale.
Just in from local shop, to be Cleaned, Checked, video made
If you're wanting to upgrade from producing dovetails with a dovetail jig, this dovetail machine will quickly pay for itself!
The G0611X features pneumatic clamps for quickly loading workpieces and a 4-sided template for cutting 1", 1-1/2", 2", and 2-1/2" dovetails.
With the ability to cut two joints at a time, the G0644X can produce a 4-sided drawer in under two minutes if the boards are prepared properly.
Also spindle heads are micro-adjustable to give you complete control of dovetail "fit."
The H9388 replacement dovetail bits are available when your stock bits start getting dull.
SPECIFICATIONS:
Motor: 1 HP, 110V/220V (prewired 220V), single-phase, 10A/5A
Minimum circuit size: 15A @ 120V, 15A @ 240V
Number of spindles: 1
Spindle speed: 18,500 RPM
Dovetail bit: 10° angle x 5/8" long
Dovetail shank: 12mm
Maximum dovetail height: 3/4"
Minimum dovetail height: 3/16"
Maximum thickness: 2-3/8"
Minimum thickness: 13/32"
Maximum stock size: 59" long x 16-1/2" wide
Minimum stock size: 7-7/8" long x 2-3/8" wide
Table size: 24" x 7-3/4"
Floor to table height: 46-7/16"
Footprint: 37" W x 21-1/4"
Overall size: 38-5/8" W x 26-1/2" x 56-7/8" H
Approximate shipping weight: 539 lbs.
FEATURES:
Micro-adjustable spindle head
Dual pneumatic clamping system
Four-way dovetail template
Cast aluminum, spring-loaded carriage
Precision-milled cast-iron table frame
Hardened and ground chrome steel slide ways
Quick air-cylinder clamp, air filter/regulator/lubricator with pressure gauge
Magnetic switch with thermal overload protection
Ball-bearing linear guides
Workpiece stops
4" dust port
Grizzly GO611X Manual Dovetailer For Sale
