STEFANI KD-R Edgebander w/Pre-Mill & Corner Rounding + EVA or PUR Glue System.
0.4 - 12 mm Edgebanding cap., panel thickness (min/max) 10 - 60 mm (0.375" - 2.375"); panel width min 51 mm (2") panel length min 140 mm (5.5") variable feed speed 10 - 20 MPM (33 - 66 FPM), min distance between panels: 610 mm (24”).
Pre-Milling unit with (2) 4 kW (5.3 HP) - 12,000 RPM motors with jumping action controlled through the PLC.
EVA + PUR Gluing System:
Quick Melt system with approx. 8 - 10-minute heat up time. Includes an SGP "QC" Glue pot with less than 1-minute change-over time.
Pressure Section: (1) Large dia. Teflon coated clutch-controlled drive roller & (3) pneumatic pressure idle rollers with opposing one-degree tilt to provide extra pressure along the top & bottom edge. ...
End Trimming Unit: 0.38 kW - 12,000 RPM (x 2 motors) End Trim units with automatic 0° - 22° on horiz. plane from the machine control with (2) pre-set positions.
T&B Trimming Unit:
Top & Bottom flush trimming, 0.75 kW - 12,000 RPM (x2). Servo controlled, with large diameter vertical and horizontal copying devices with precise digital indicators.
Corner Rounding Unit:
0.60 kW - 12,000 RPM (x2). The "ROUND-K" Unit is designed to work as an additional set of trimmers for rounding the top/bottom as well as the front/rear corners of work piece with 3mm PVC edges.
Profile Scraping Unit: Top & Bottom for thick PVC. The unit is equipped with pneumatic in/out positioning through the controller.
Flat Glue Scrapers: Top & Bottom glue scraping unit is for the finishing of thin PVC. It is equipped with two throwaway knives, vertical rotating copiers and blowers for tool cleaning.
Buffing Unit: Top & Bottom oscillating buffing with 0.2 kW - 3,000 RPM motor (x2), The unit cleans and polishes the panel edge. The unit oscillates to utilize the full width of the wheel and prevent rounding of the panel’s leading edge.
Operator & Machine Control: "Startouch" Controller; The Stefani KD comes equipped with the new "Startouch" controller.
*** Please click the link for full description***
Scmi Stefani KD-R Edgebander
