K360 ERT-1 HP Servo machines are equipped with: RT-VP Pre-Milling Unit 2 × 2 HP motors 19,000 RPM Diamond cutterheads EVA Glue Pot Teflon-coated Approx. 8–12 minute heat-up time End Trim Unit Automatic pneumatic positioning Radius and straight trimming Top/Bottom Trim Unit 2 × 0.7 HP motors 12,000 RPM Corner Rounding Unit Diamond cutterhead Automatic changeover for thin tape and 3 mm PVC Profile Scraper Glue Scraper Buffing Unit Servo-Controlled Electronic Axes The HP Servo model allows electronic positioning of key stations through the touchscreen. This reduces setup time dramatically when switching between: 1 mm PVC 3 mm PVC Wood edging Different panel thicknesses For a custom cabinet shop running mixed jobs daily, the servo package can easily save 15–30 minutes of setup time per day compared with manually adjusted machines.
