SPECS:
Spindle Speed (RPM) 4000/6000/8000/10000
Maximum Spindle Diameter (In.) 1-1/4
Spindles Included 1-1/4″
Spindle Size Under Nut (In.) 4
Spindle Travel (In.) 4
Reversible Yes
Maximum Diameter Cutter Above Table (In.) 7-1/2
Maximum Diameter Cutter Below Table (In.) 6
Table Opening Diameter (In.) 6-19/64
Table Inserts (In.) 2
Table Insert Opening Diameter (In.) 2-9/16, 4-5/16
Table Size (L x W) (In.) 32-1/4 x 26-3/4
Table T-Slot (In.) 3/4 x 3/8
Table Height from Floor (In.) 33-1/4
Fence Size (L x H) (In.) 16 x 4-3/4
Fence Travel (Major and Minor) (In.) 4, 1
Dust Port Outside Diameter (In.) 4
Dust Collection Minimum CFM Required (CFM) 600
Electrical Controls Yes
Motor Power (HP) 3
Motor Phase (PH) 1
Motor Voltage (V.) 230
Prewired Voltage (V.) 230
Motor Amps 14
FEATURES:
Four-speeds 4000, 6000, 8000, 10000 RPM let you select the best speed and torque for different cutter diameters
Powerful 3HP, 1Ph motor with magnetic controls
Poly-V-belt transfers maximum power to the spindle
Large 26-3/4” X 32-1/4” precision ground cast iron table provides a durable work area, predrilled for power feeder
Spindle height scale
Starting pins for irregular shaping
Extruded aluminum fence comes with T-Slots and 2 feather board hold-downs
Extra-large chrome handwheel is conveniently located for fast, easy and accurate spindle height adjustments
Reversible spindle speeds for diverse shaping jobs
4″ Dust port built into fence for convenient hookup to any dust collection system
Spindle lock for safe and easy cutter set-up
NOTES:
🔥 10 BLADE PRO MACHINERY
📞 1‑833‑410‑2523
📞 1‑833‑4‑10BLADE
📸 IG: @10bladepromachine
📘 FB: facebook.com/10BladeProMachinery
🚚 Immediate Pickup — NO TAX – NO FREIGHT – NO REGRETS
New-in-crate. Unused. Sold exactly as received.
