UNDER POWER FOR INSPECTION UNTIL 9/5/22
MAIN TECHNICAL FEATURES
Work area consists of 4 air tables
Main saw power; 21,3 kW/60 Hz (30 HP)
Scoring Saw power; 2,6 kW/60 Hz (3,6 HP)
Controlled pressure beam
Side aligner
Pusher arm (7) grippers
Secondary gripper (Twin push)
Max Sawblade; 400mm (16")
Max scoring blade; 200mm (8")
Quickchange Blade System
Maximum length of cut; 4500 mm
Maximum saw blade projection; 108 mm
Maximum gripper opening; 100 mm
Minimum size of boards on lift table; 1830 x 915 mm
Maximum size of boards on lift table; 4500 x 2200 mm
Maximum height of the pile of boards; 630 mm
Minimum thickness loadable by lift table; 10 mm
Height of work table; 985 mm
Lift table weight capacity; 5 t
Max size of material; 4400x2200
Powered rollers on infeed table as well as lift table
Label printer on support stand @ work area
